BIG DUCT SPLIT TYPE
Floor StandingBIG DUCT SPLIT TYPE
🏢 Commercial AC
A high-efficiency, ducted inverter system balances industrial power with cost-effective operation for large-scale floor installations.
Key Features
- High Efficiency
- Latest CAN Bus Communication
- Long Connection Pipe and Big Height Difference PID Intelligent Capacity Adjustment
- Energy Efficient
- High External static pressure design
- Intelligent filter cleaning reminding function
- Gold Fin ODU
- Wired controller
- Nylon Air Filter
Available Capacity
Inverter
₱360,997
Specifications
| TUMD250PH/A-S(P) | Unit | Value |
|---|---|---|
| Power Supply | AWG | 220v/60hz(I); 380v/3ph/60hz(O) |
| Ref. Pipe Size | inch | 3/8"; 7/8" |
| Dimensions | IDU (WxDxH) | mm | 1,520x840x450 |
| Breaker Size | A | 10A(I); 25A(O) |
| Communication Wire Qty. | AWG | AWG #14 X 2 |
| Capacity | HP | 9.0 HP |
| Sound Pressure Level | dB(A) | IDU: 53 ODU: |
| Drain Pipe | inch | 1" |
| Net Weight / Gross Weight | kg | IDU: 105 ODU: 127 |
| Power Supply Wire Size | AWG | AWG #12 X 4 |
Inverter
₱420,995
Specifications
| TUMD300PH/A-S(P) | Unit | Value |
|---|---|---|
| Power Supply | AWG | 220v/60hz(I); 380v/3ph/60hz(O) |
| Ref. Pipe Size | inch | 1"; 1/2" |
| Net Weight / Gross Weight | kg | IDU: 110 ODU: 155 |
| Breaker Size | A | 10A(I); 25A (O) |
| Communication Wire Qty. | AWG | AWG #14 X 2 |
| Capacity | HP | 10.71 HP |
| Sound Pressure Level | dB(A) | IDU: 55 ODU: |
| Drain Pipe | inch | 1" |
| Power Supply Wire Size | AWG | AWG #12 X 4 |
Inverter
₱570,995
Specifications
| TUMD400PH/A-M(P) | Unit | Value |
|---|---|---|
| Power Supply | AWG | 380v/3ph/60hz |
| Ref. Pipe Size | inch | 1" ; 1/2" |
| Net Weight / Gross Weight | kg | IDU: 155 ODU:180 |
| Breaker Size | A | 10A(I); 32A(O) |
| Capacity | HP | 13.61 |
| Sound Pressure Level | dB(A) | IDU: 56 ODU: |
| Drain Pipe | inch | 1" |
| Power Supply Wire Size | AWG | AWG#12 X 4 |
| Communication Wire Qty. | AWG | AWG#14 X 2 |
